Phonic XP 3000 Service Manual

PHONIC CORPORATION
Page 23
XP3000/3000(B) S ERVICE MANUAL
CH1/CH2 CONTROL SCHEMATIC-2
CH1/CH2 CONTROL PCB-PART LIST
Ref. Phonic Part No. Specifications
R117.138.309A.309B 008-01032-600-0 CHIP RES. 10K J 0603
R101.103.122.124.345A.345B 008-01042-600-0 CHIP RES. 100K J 0603
R108.129 008-01232-600-0 CHIP RES. 12K J 0603
R311A.311B 008-01242-600-0 CHIP RES. 120K J 0603
R120.141 008-01512-600-0 CHIP RES. 150 J 0603
R104-107.125-128 008-01532-600-0 CHIP RES. 15K J 0603
R113.114.115.134.135.136 008-02212-600-0 CHIP RES. 220 J 0603
R102.112.123.133 008-02232-600-0 CHIP RES. 22K J 0603
R119.140 008-03322-600-0 CHIP RES. 3.3K J 0603
R310A.310B 008-03332-600-0 CHIP RES. 33K J 0603
R121.142 008-03922-600-0 CHIP RES. 3.9K J 0603
R110.131 008-04322-600-0 CHIP RES. 4.3K J 0603
R118.139 008-04332-600-0 CHIP RES. 43KJ 0603
R148.149 008-04712-600-0 CHIP RES. 470J 0603
R343A.343B..344A.344B 008-04722-600-0 CHIP RES. 4.7K J 0603
R111.132 008-04732-600-0 CHIP RES. 47K J 0603
R150.151.152.154.155.156 008-05132-600-0 CHIP RES. 51K J 0603
R109.130 008-08232-600-0 CHIP RES. 82K J 0603
C146 039-10324-220-0 CHIP C/C 0.01MF J 50V
0603
C106.107.117.118 039-10405-220-0 CHIP C/C 0.1UF K 16V 0603
C130.141 039-12325-220-0 CHIP C/C 0.012UF 50V K
0603 X7R
C124.126.127.128.135.137.138.1
39
039-18325-220-0 CHIP C/C 0.018UF 50V K
0603 X7R
C101.102.112.113 039-22024-220-0 CHIP C/C 22PF J 50V 0603
C110.121 039-33024-220-0 CHIP C/C 33PF J 50V 0603
C103.104.105.114.115.116 039-33435-220-0 CHIP. C/C 0.33MF 10V K
0603
C129.131.132.133.140.142.143.1
44
039-39315-220-0 CHIP C/C 0.039MF K 25V
0603
C125.136 039-68225-220-0 CHIP RES. 0.0068UF K 50V
0603 X7R
IC1-6 160-00021-300-0 IC NJM2068 SMD JRC
290-34640-304-0 PIII2000/2000B/3000/3000B
D+E+F PCB

Phonic XP 3000 Specifications

General

Amplifier Type	Professional Power Amplifier
Number of Channels	2
THD	<0.03%
Signal-to-Noise Ratio	>100dB
Input Impedance	20 kOhms Balanced, 10 kOhms Unbalanced
Cooling	Variable speed fan
Connectors Input	XLR and 1/4" TRS
Power Output	3000W
Input Sensitivity	0.775V / 1.0V / 1.4V
Frequency Response	20Hz - 20kHz
Protection	Short Circuit, Thermal, Overload, DC Fault
Connectors Output	Speakon, Binding Post
Damping Factor	>300
