Phonic XP 3000 Service Manual

PHONIC CORPORATION
Page 25
XP3000/3000(B) S ERVICE MANUAL
MISCELLANEOUS ITEMS
MISCELLANEOUS ITEMS
Ref. Phonic Part No. Specifications
POWER SW 210-03201-080-0 SSA/SW
PL2-2-21-C-2-BK/BK-P2
BREAKER 210-1400 -000-0 BREAKER 0A
211-17000-410-0 BINDING POST BP-47-2P
212-10010-650-0 1P WAFER/P 100MM
UL1015#14 RED
PIN2 212-10010-660-0 1P WAFER/P 150MM
UL1015#14 ORANGE
PIN4 212-10010-670-0 1P WAFER/P 150MM
UL1015#14 YLW
POWER SW 212-10023-360-6 2P WAFER/P 1617#14 AWG
420MM BLUE
POWER SW 212-10023-370-6 2P WAFER/P 1617#14 AWG
370MM RED
307-00000-070-0 CORD CONNECTOR C5
315-00000-000-0 LUG D4 FOR GROUND
321-00000-020-0 CABEL TIE 140MM
321-00000-070-0 CABLE TIE HW-100MM
347-00000-200-0 FAN SP802524H 24VDC
510-20930-303-0 PANEL T=1.5SECC XP3000
510-20930-403-0 PANEL T=1.5 SECC
XP3000B
511-20620-103-0 BACK PANEL SECC
T=1.2mm XP2000/3000(B)
516-20430-102-0 TOP COV
524-20007-012-0 HANDLE XP2000/3000(B)
525-00009-100-0 FEET D26.5*11 BLK
528-00000-000-0 FAN NET WHT PWA2200
8"
529-20026-001-0 LENS PMMA 45.6*11.6
540-20380-120-0 R/KNOB D9.5*10.0MM BLK
540-20390-120-0 R/KNOB D18*18MM BLK
FIX X'MER 552-10174-480-0 LOCKING CABLE FIXED
WC-11
552-20048-420-0 ADHESIVE FIXED
FW-5D-3M
1
2

Phonic XP 3000 Specifications

General

Amplifier Type	Professional Power Amplifier
Number of Channels	2
THD	<0.03%
Signal-to-Noise Ratio	>100dB
Input Impedance	20 kOhms Balanced, 10 kOhms Unbalanced
Cooling	Variable speed fan
Connectors Input	XLR and 1/4" TRS
Power Output	3000W
Input Sensitivity	0.775V / 1.0V / 1.4V
Frequency Response	20Hz - 20kHz
Protection	Short Circuit, Thermal, Overload, DC Fault
Connectors Output	Speakon, Binding Post
Damping Factor	>300
