Phonic XP 3000 Service Manual

PHONIC CORPORATION
Page 13
XP3000/3000(B) S ERVICE MANUAL
POWER AMPLIFER PCB-PART LIST
POWER AMPLIFIER PCB-PART LIST
Ref. Phonic Part No. Specifications
C222 042-03020-000-0 C/C2 3PF C 50V 5
C220.221 042-10124-050-0 C/C2 100PF J 50V T
C207.209.225 042-10225-050-0 C/C2 0.001MF K 50V 5 T
C214.215 042-10345-160-6 C/C2 0.01UF K 100V T
C1A.231.315.316 042-10426-050-0 C/C2 0.1MF M 50V 5 T
C223.230.224.227 042-104A8-000-0 C/C2 0.1MF Z 250V 5
C229 042-201A5-000-0 C/C2 200PF K 250V
C206 042-33024-050-0 C/C2 33PF J 50V 5 T
C228 042-391A4-050-0 C/C2 390PF J 250V 5 T
C307 042-47124-050-0 C/C2 470PF J 50V 5 T
C213.216 042-47164-050-0 C/C2 470PF J 350V 5 T
C202.204 042-47325-050-0 C/C2 0.047MF K 50V 5 T
C218 042-56224-050-0 C/C2 0.0056MF J 50V T
C304.305 046-10414-060-0 M/C 0.1MF J 100V 5 T
ZD207 090-01123-000-0 ZEN/DIODE 12V J 0.5W
UNIZON
ZD2A.3A 090-01273-010-0 ZEN/DIODE 27V K 0.5W
ZD203.204.205.301.302 090-01682-000-0 ZEN/DIODE 6.8V J0.5W
UNIZO
ZD201.202 090-01752-010-0 ZEN/DIODE 7V5 K 0.5W
FAIRCH
ZD1A.206 090-01912-000-0 ZEN/DIODE 9.1V J 0.5W FAI
D201.202.203.206.303.304 090-02000-020-0 DIODE 1N4148 T
Q302.306.308.309.310.312.314.3
15
120-00000-800-0 TRAN. 2SC1815 GR
TOSHIBA
Q201 120-00001-400-0 TRAN. 2N5551
MOTOROLA
Q208 120-00009-700-0
TRAN. BC546B PHILIPS(
BC550)
Q307.311.313 121-00000-200-0 TRAN. 2SA1015 GR
TOSHIBA
Q1A.204.214.232.233 121-00000-300-0 TRAN. 2N5401
MOTOROLA
Q207 121-00007-500-0 TRAN. BC556B PHILIPS
(BC560)
290-34640-400-0 XP3000/B MOSFET (H) PCB
6

Phonic XP 3000 Specifications

General

Amplifier Type	Professional Power Amplifier
Number of Channels	2
THD	<0.03%
Signal-to-Noise Ratio	>100dB
Input Impedance	20 kOhms Balanced, 10 kOhms Unbalanced
Cooling	Variable speed fan
Connectors Input	XLR and 1/4" TRS
Power Output	3000W
Input Sensitivity	0.775V / 1.0V / 1.4V
Frequency Response	20Hz - 20kHz
Protection	Short Circuit, Thermal, Overload, DC Fault
Connectors Output	Speakon, Binding Post
Damping Factor	>300
