TECHNICAL DATA 250
Version 250
Engine Single-cylinder, four-stroke
Bore x stroke 72 x 60 mm
Cubic capacity 244.29 cm³
Compression ratio 10.5 - 11.5 : 1
Ignition advance (before TDC) variable (integrated into the ignition
system)
Spark plug CHAMPION RG 4 PHP
Maximum speed 125 km/h
Valve clearance intake: 0.10 mm
discharge: 0.15 mm
TECHNICAL DATA - BEVERLY 250
Overall width 875 mm
Overall length 2110 mm
Overall height 1480 mm
Wheelbase 1470 mm
Saddle height 790 mm
66
