Exhaust muffler absorption type, with a 3-way
catalytic converter.
Fuel supply throttle valve dia. 32 mm and single
injector
Electronic ignition inductive, high efficiency
integrated with the injection
system, with variable timing and
separate HV coil.
Cooling Forced liquid circulation cooling.
Lubrication Engine lubrication with lobe pump
(inside crankcase) controlled by a
chain with double filter: mesh and
paper.
Transmission With automatic expandable pulley
variator with torque server, V belt,
self-ventilating automatic
centrifugal dry clutch, gear
reduction unit and transmission
housing with forced air circulation
cooling.
Front brake disc brake, diameter 260 mm
(right-hand side of scooter), with
hydraulic servo operated from the
handlebar with the right-hand
lever.
Rear brake disc brake, diameter 260 mm, with
hydraulic control operated from the
handlebar.
Front wheel: alloy rim:16" x 3.50
Rear wheel alloy rim: 16" x 3.50
Front tyre Without inner tube: 110/70-16"
67
