- Remove the wheel and check using the appro-
priate tools that the axial run-out of the brake
surface is within the prescribed limits.
- If this is not the case, replace the disc and repeat
the test.
WHEN INSTALLING, THOROUGHLY CLEAN THE DISC
AND ITS SEAT ON THE HUB.
Characteristic
Max. axial run-out
0.1 mm
Front brake pads
Removal
Proceed as follows:
- Remove the front calliper.
- Loosen the two pins shown in the figure that lock
the two pads.
- Remove the pads, being careful with the pad
spring clamp.
- Check the thickness of the friction material of the
pads.
- Replace the pads if the thickness is below the
minimum value.
- The replacement must be made with greater re-
sidual thickness if the pad has not worn evenly. A
0.5 mm thickness difference in the residual friction
material is permitted.
Characteristic
Minimum value
1.5 mm
Beverly Tourer 250 i.e. Braking system
BRAK SYS - 233
