The vehicle provides power and allows a maximum speed of 45 km/h.
02_05
When the traction battery charge is close to 0% the reserve warning light remains
steadily. This means you need to recharge from the electricity mains.
02_06
Recharge from the mains (02_06, 02_07, 02_08, 02_09, 02_10)
To recharge by mains supply it must be necessary that the key is switched «OFF».
Lift the saddle and remove the cable with charging plug. Run the cable in its place
next to the hinge of the saddle and close it so that the cable activates the switch. When
you do this, the warning light will turn on. The drive is inhibited until the cable is re-
moved from the position described above.
This vehicle is equipped with a «CEI 69-6 STANDARD PLUG», which is required for
charging from public charging stations. In order to use the home network it is neces-
sary to use the adaptor supplied with the vehicle, positioned on the right side of the
front top box or in the helmet compartment, depending on the version. The power
cable is fitted with a fused protection device.
CAUTION
DO NOT, UNDER ANY CIRCUMSTANCES, REMOVE THE COVER FROM THE
BATTERY COMPARTMENT. CONTACT AUTHORISED PIAGGIO ASSISTANCE
CENTRES ONLY.
30
