WARNING
USED BATTERIES ARE HARMFUL FOR THE ENVIRONMENT. COLLECTION
AND DISPOSAL SHOULD BE CARRIED OUT IN COMPLIANCE WITH REGULA-
TIONS IN FORCE.
03_08
Fuses (03_08)
The electrical system is protected by a 15A fuse valve «B» located over the battery.
Before replacing a blown fuse, find and solve the problem that caused it to blow. Do
not replace the fuse with any alternative form of conductor
03_09
Front light group (03_09, 03_10, 03_11, 03_12)
To access the headlight bulbs (1 twin-filament high/low beam bulb and 1 bulb for day-
light running light), proceed as follows:
1. Loosen the 3 screws A of the glass retainer and remove it to access the
daylight running light bulb.
2. Turn the lock B to access to the twin-filament bulb.
To refit, follow the same steps but in reverse order.
48
