PIAGGIO MP3 400 hpe E5 2021 - Page 46

- Remove the discs separation spring.
- Remove the semi-trimmed duct disc (trimmed on
one side).
- Remove a conductor disc.
- Remove the discs clearance recovery spring
- Remove a duct metallic disc.
- Remove a conductor disc (trimmed on both
sides).
Engine MP3 400 hpe E5
ENG - 46
