PIAGGIO MP3 400 hpe E5 2021 - Page 45

- Using pliers remove the lock circlips.
- Disengage the upper ring of the specific tool.
- Remove the outer ring with the seat for the Bel-
leville spring.
- Remove the Belleville spring.
- Remove the spring door upper disc.
MP3 400 hpe E5 Engine
ENG - 45
