PIAGGIO MP3 400 hpe E5 2021 - Pulley System Operations

CLUTCH OUTPUT SHAFT ROLLER CASING IN-
SPECTION
- Using specific tools, remove the roller casing
Specific tooling
001467Y006 Pliers to extract 20 mm bearings
001467Y007 Driver for OD 54-mm bearings
- Insert a new roller casing and set it with specific
tools.
Specific tooling
020084Y punch ø 20
MP3 400 hpe E5 Engine
ENG - 55
