Pin retaining collar
- Use the tool equipped with medium length pins
in "C" position screwing them from the inside of the
tool.
- Install the driven pulley into the tool providing the
support of an appendix against a pin.
- Ensure the centring of the driven pulley by means
of the key inserted on the nut.
Specific tooling
020444Y Tool for installing/removing clutch
on/from driven pulley
020444Y009 wrench 46 x 55
- Turn the key to unscrew the nut.
- Adjust the specific tool command screw to re-
lease the torque server spring.
Engine MP3 400 hpe E5
ENG - 56
