Refitting the intermediate gear
- Lubricate the sliding surfaces and insert the in-
termediate gear in its seat.
Refitting the flywheel magneto
- Place the tab.
- Insert the magneto flywheel on the crankshaft.
- Insert the washer.
MP3 400 hpe E5 Engine
ENG - 83
