- The starter should disconnect progressively by
means of electrical heating.
- Check the starter resistance when adjusted to the
ambient temperature.
Characteristic
ambient temperature
24° C
Electric characteristic
Automatic starter resistance
6 Ω ± 5 %
- Use battery to power the automatic starter and
check that piston protrudes as much as possible.
- The correct warm up time depends on the ambi-
ent temperature.
- If protrusion, resistance or timing values are dif-
ferent from the ones prescribed, replace the start-
er.
Characteristic
Battery
12V-9Ah
max. protrusion
15 mm
max. time
15 min
- Fit the starter, the support bracket and the pro-
tection with the screw indicated in the figure.
Engine MSS ZIP 100 4T
ENG - 124
