Rocker arms support assy.

CAMSHAFT SUPPORT

Code

Action Duration

1 001049 Valve clearance - Adjustment

2 001148 Valve rocking levers - Replacement

3 001044 Camshaft - Replacement

Time MSS ZIP 100 4T

TIME - 158
