Electric devices

ELECTRICAL DEVICES

Code

Action Duration

1 005001 Electrical system - Replacement

2 005009 Voltage regulator - Replacement

3 001094 Spark plug cap - Replacement

4 001023 Control unit - Replacement

5 005114 Electrical system - Service

MSS ZIP 100 4T Time

TIME - 183
