Steering column

STEERING

Code

Action Duration

1 003048 Fork oil seal - Replacement

2 003076 Fork sheath - Replacement

3 003079 Fork stem - Replacement

4 003010 Front suspension - Service

Time MSS ZIP 100 4T
