01_15
01_16
Saddleopeningremotecontrol (01_15, 01_16)
The scooter is fitted with a remote control to open the saddle. This remote control is
supplied together with the keys and it has been programmed to control the opening
device control unit at the manufacturing stage. If the remote control is lost, a new one
can be requested and programmed at any Authorised Piaggio Service Centre. The
remote control is powered by inner batteries that get discharged after extended used;
If the green LED turns on when the button is pressed, the remote control is working
properly. You may need to replace the batteries if the remote control fails or if its range
of operation is reduced. To separate the two halves of the remote control, insert the
blade of a plain slot screwdriver at one point on the edge and slide it all around. When
the remote control is open, remove the two batteries from the contact terminal. Install
the two new CR1616 3V batteries with the positive pole facing the contact terminal.
Reassemble the remote control by pressing the two clip-on halves gently with your
fingers.
To open the saddle without using the remote control, follow the instructions in the
"Opening the saddle to reach the helmet compartment" or "Opening the saddle to
reach the helmet compartment in an emergency" sections.
Remotecontrolprogramming
Follow these steps to program the remote controls:
1. Insert the remote control key to be programmed in the steering lock key block.
2. Turn the key to «ON», press the button on the remote control, release the button,
then turn the key back to «OFF» within four seconds of turning «ON».
3. Wait 1 to 8 seconds.
4. Repeat steps 2 and 3 four more times without removing the key.
18
