HOWEVER, THIS IS SIGNALLED BY THE CORRESPONDING WARNING LIGHT
FITTED ON THE INSTRUMENT PANEL
01_22
Openingthesaddletoaccessthehelmetcompartmentinanemerge
ncy (01_22, 01_23, 01_24)
For scooters with two levers
With the key in position "OFF" or "ON" it is possible to open the cover of the fuel tank
filler neck.
Pressing the levers allows you to open the saddle or the cover over the rear compart-
ment of the scooter.
WARNING
OBJECTS INAPPROPRIATELY PLACED INSIDE THE HELMET COMPARTMENT
MAY DEFORM THE SADDLE AND PREVENT THE COURTESY LIGHT FROM
TURNING OFF, WHICH MAY RESULT IN BATTERY DISCHARGE.
01_23
For scooters with one lever
With the key in position "OFF" or "ON" it is possible to open the cover of the fuel tank
filler neck.
Press the lever to open the rear compartment of the scooter.
To open the saddle it is necessary to press the metallic lever of the seat lock manually
towards the left of the scooter (as seen in the direction of travel). For this operation
you have to reach into the inside of the luggage compartment after having opened the
rear cover.
23
