03_31
03_32
WARNING
HIGH- AND LOW-BEAM BULBS ARE HALOGEN TYPE: DO NOT TOUCH THEM
WITH YOUR FINGERS TO AVOID DAMAGING THEIR FUNCTION.
03_33
Rearopticalunit (03_33, 03_34)
Open the rear flap (boot door), loosen the two fixing screws, "D", and remove the
taillight assembly from its housing.
Follow this procedure to remove the bulbs:
Side lights - Snap-on central bulb " A"
Stop lights - Side bulbs "B" in bayonet socket making a 30° clockwise turn.
67
