X8 250 I.E.TECHNICAL DATA
Electronic ignition inductive, high efficiency
integrated with the injection
system, with variable timing and
separate HV coil.
Fuel system throttle body diam. 32 mm and
single injector
Transmission With automatic expandable pulley
variator with torque server, V belt,
self-ventilating automatic
centrifugal dry clutch, gear
reduction unit and transmission
housing with forced air circulation
cooling.
Lubrication Engine lubrication with lobe pump
(inside crankcase), chain-driven,
with double filter: mesh and paper.
Cooling Forced fluid circulation, with
engine driven pump; 3-way
thermostat to pump intake.
Exhaust muffler absorption type, with a 3-way
catalytic converter.
Front suspension Hydraulic telescopic fork with Ø 35-
mm stem
Rear suspension Single arm with two double-acting
hydraulic shock absorbers and
preloading adjustment in 4
positions.
79
