Checks
Before using the vehicle, check:
1. that the fuel tank is full.
2. The oil level in the rear hub.
3. engine oil level (see section «Engine oil level»).
4. That tyres are properly inflated.
5. correct functioning of headlights, rear taillight and turn indicators.
6. The correct functioning of the front and rear brakes.
7. The fluid level in the front brake pump tank.
02_01
Refuelling (02_01, 02_02)
Fill fuel tank«A» with unleaded petrol (minimum octane rating = 95).
When the fuel reaches the reserve level, the warning light fitted on the instrument
panel lights up.
CAUTION
SHUT OFF THE ENGINE BEFORE REFUELLING WITH PETROL. PETROL IS
HIGHLY FLAMMABLE. DO NOT LET PETROL SPILL FROM THE TANK OR WHILE
REFUELLING
CAUTION
DO NOT BRING NAKED FLAMES OR CIGARETTES NEAR THE MOUTH OF THE
FUEL TANK: FIRE HAZARD. ALSO AVOID INHALING HARMFUL VAPOURS.
16
2 Use

PIAGGIO ZIP 50 4T Specifications

General

Engine Type	Single-cylinder, 4-stroke
Cooling System	Air cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Max Torque	3.8 Nm at 6, 500 rpm
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Seat Height	765 mm
Width	680 mm
Weight	89 kg
Length	1, 700 mm
