PIAGGIO ZIP 50 4T User Manual

01_01
Dashboard (01_01)
A = Speedometer
B = Low fuel warning light
C = Turn indicator warning light
D = Preset warning light
F = Starter button
G = Odometer
H = High-beam headlight warning light
I = Horn button
L = Turn indicator switch
M = Headlight switch
01_02
Keyswitch (01_02)
LOCK = Ignition to earth, extractable key, steering lock engaged.
OFF = Ignition to earth, extractable key, steering lock disengaged.
ON = Ready to start, steering lock disengaged, key cannot be extracted.
In the position«ON» and «OFF» it is possible to open the front glove-box pushing the
key switch, in position LOCK the glove-box is closed.
8
1 Vehicle

PIAGGIO ZIP 50 4T Specifications

General

Engine Type	Single-cylinder, 4-stroke
Cooling System	Air cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Max Torque	3.8 Nm at 6, 500 rpm
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Seat Height	765 mm
Width	680 mm
Weight	89 kg
Length	1, 700 mm
