PIAGGIO ZIP 50 4T User Manual

01_03
Lockingthesteeringwheel (01_03)
Turn the handlebar to the left (as far as it will go), turn the key to «LOCK» and remove
the key.
CAUTION
DO NOT TURN THE KEY TO «LOCK» OR «KEY OFF» WHILE RIDING.
01_04
Switchdirectionindicators (01_04)
0 = Turn indicators off.
D = Turn indicators on (right side)
S = Turn indicators on (left side)
The positions «D» and «S» are unstable. The switch lever «B» always returns to
«0». Push the lever to switch off the turn indicators.
9
1 Vehicle

PIAGGIO ZIP 50 4T Specifications

General

Engine Type	Single-cylinder, 4-stroke
Cooling System	Air cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Max Torque	3.8 Nm at 6, 500 rpm
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Seat Height	765 mm
Width	680 mm
Weight	89 kg
Length	1, 700 mm
