AFTER FITTING NEW BRAKE PADS DO NOT USE THE VEHICLE UNTIL YOU

HAVE ACTIVATED THE BRAKE LEVER REPEATEDLY TO POSITION THE PADS

AND RESTORE THE LEVER STROKE TO ITS CORRECT POSITION.

CAUTION

BRAKING SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE LEVER STROKE.

03_27

Reardrumbrake (03_27)

Actuate on the set screw «A» indicated on the figure bearing in mind that the wheel

must rotate freely when the control lever is in neutral.

CAUTION

BRAKING SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE LEVER STROKE.

3 Maintenance
