Fuel supply Gravity feed, unleaded petrol,
through carburettor.
Lubrication Engine lubrication with lobe pump
(inside the crankcase) controlled
by chain and double filter: mesh
and centrifugal.
Cooling Forced-circulation air cooling.
Transmission With automatic expandable pulley
variator, torque server, V-belt,
automatic clutch, gear reduction
unit.
Fuel tank In plastic, with a capacity of ~ 7.5 l
(approximate value, including ~ 1.2
l reserve)
Front suspension with telescopic fork.
Rear suspension fitted with spring and coaxial
hydraulic shock absorber. Chassis
to engine support with swinging
arm.
Front wheel With 2.15 X 10" rims
Rear wheel With 3 X 10" rims
Front tyre 100/80-10"
Rear tyre 120/70-10"
Exhaust muffler Absorption type.
Electronic ignition Electronic ignition device with
incorporated HV coil.
Chassis Single spar and stamped sheets.
53
4 Technicaldata

PIAGGIO ZIP 50 4T Specifications

General

Engine Type	Single-cylinder, 4-stroke
Cooling System	Air cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Max Torque	3.8 Nm at 6, 500 rpm
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Seat Height	765 mm
Width	680 mm
Weight	89 kg
Length	1, 700 mm
