PIAGGIO ZIP 50 4T User Manual

Tyre pressure (100 cc) Front wheel: 1.3 bar
Rear wheel: 1.6 ÷ 1.8 bar
Ignition type Capacitive discharge electronic
ignition, with incorporated HV coil
Chassis type Welded tubular steel chassis with
stamped sheet reinforcements
Front brake Disc (220 mm diameter) with
hydraulic control (lever on the right
side of the handlebar).
Rear brake Drum brake (140 mm diameter)
with expanding shoes,
mechanically operated
Engine oil ~ 850 cc (recommended oil:
SELENIA HI SCOOTER 4 Tech)
Rear hub (100 cc) approx. 80 cm³
56
4 Technicaldata

PIAGGIO ZIP 50 4T Specifications

General

Engine Type	Single-cylinder, 4-stroke
Cooling System	Air cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Max Torque	3.8 Nm at 6, 500 rpm
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Seat Height	765 mm
Width	680 mm
Weight	89 kg
Length	1, 700 mm
