Picard Spitfire - Minimal Distance Required between the Oven and Flammable Material; Gas Capacity and Pressure

17
MINIMAL DISTANCE REQUIRED BETWEEN THE OVEN AND FLAMMABLE MATERIAL
COMBUSTIBLE AND NON-COMBUSTIBLE MATERIAL
Manhole side
24 inches of clearance
Ovens top
16 inches of clearance
Ovens back and side
0 inch of clearance
Ovens floor
0 inch of clearance non-combustible materiel only
GAS CAPACITY AND PRESSURE
MODEL
ORIFICE
TYPE OF GAS
CAPACITY BTU
LINE PRESSURE
SF-8-16
5.6mm
Propane
150,000
5’’ -14’’ W.C.
SF-8-16
5.6mm
Natural
150,000
SF-8-24
7.5mm
Propane
200,000
SF-8-24
7.5mm
Natural
200,000
IMPORTANT!
The high limit temperature alarm must always be adjusted to 625 degrees Fahrenheit or 330 degrees Celsius.
NOTE
Picard gas units are manufactured to only be used with the type of gas specified on the rating plates.
The installation must conform to local codes, or in the absence of local codes, to the
ANSI Z223.1 / NFPA 54 (National Fuel Gas Code) CAN/CSA-B149.1 (Natural and or propane gas installation code)
WARNING!
Improper installation, adjustment, alteration, service or maintenance could result in property damage, injury or even death!
