TROUBLE SHOOTING
Problem
Cause
Solution
The oven won’t turn on after
pressing the main power
button.
The oven has no
electricity.
-Verify that the switch behind the bottom right side
access door is in the ON position.
-Verify that the oven is plug into an electric source.
-Verify the fuses in the electric box located on the
oven’s roof. (p.27)
The oven’s shelves won’t turn
after having pressed the
shelves rotation button.
The electrical circuit
contacts for the shelves
rotation have been cut.
-Verify that the bottom left access door is well
positioned
.-Verify that the shelves rotation motor’s base
hasn’t lifted and that it’s not engaging the security
dispositive.
-The loading door must be closed to permit
shelves rotation.(Québec)
-Push the stop rotation button to reset the security
line.
- Verify the fuses in the electric box located on the
oven’s roof. (p.27)
The burner’s ventilator isn’t
starting after having pushed the
burner’s start button.
The ventilator isn’t
receiving the start signal.
-Verify that the hood vacuum is working.
- Verify the fuses, in the electric box located on the
oven’s roof. (p.27)
The burner’s ventilator is
working but the burner isn’t
lighting after a 30 second purge
cycle.
The gas line may be cut.
-Verify that the gas valve on your gas line is in the
open position.
-Verify that the gas pressure is between 5 and 14
inches of water column.
The Igniter isn’t
functioning correctly
- Verify the fuses in the electric box, located on the
oven’s roof. (p.27)
-Verify that the burner is clean. Residue can block
the gas at the igniter.
-Change the igniter kit.
The burner lights but
extinguishes shortly after.
The flame detector is
malfunctioning.
-Make sure that the flame detector’s rod isn’t
touching any corposants.
-Verify That the flame detector is located at 1/4"
over the burner.
-Verify that no residue harms the flame detector.
-Clean the flame detector’s rod with a steel wool
pad.
-Change the flame detector
The oven’s alarm is sounding
for 2 seconds every 3 minutes.
The cooling fan for the
control panel is
malfunctioning.
-Change the fan.
The burner goes out when it
reaches the set temperature.
The low fire parameters
adjustments are
inadequate.
Communicate with Picard Ovens Customer
Service department to schedule a readjustment of
the burner’s parameters.
