Page 7.12
SECTION 7 - MAINTENANCE INFORMATION
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
Table 7.11 - Linearity Verication Test Results For Resolver Simulator -xxxx05
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equip-
ment Used:
Position
Measured
Sin
Minimum Maximum
Measured
Cos
Minimum Maximum
Result (delete
as appropriate)
-180.00 0.000 0.155 30.690 31.310
Pass / Fail
-170.00 5.201 5.565 30.221 30.837
Pass / Fail
-160.00 10.395 10.811 28.830 29.431
Pass / Fail
-150.00 15.268 15.733 26.558 27.136
Pass / Fail
-140.00 19.672 20.181 23.474 24.021
Pass / Fail
-130.00 23.474 24.021 19.672 20.181
Pass / Fail
-120.00 26.558 27.136 15.268 15.733
Pass / Fail
-110.00 28.830 29.431 10.395 10.811
Pass / Fail
-100.00 30.221 30.837 5.201 5.565
Pass / Fail
-90.00 30.690 31.310 0.000 0.155
Pass / Fail
-80.00 30.221 30.837 5.201 5.565
Pass / Fail
-70.00 28.830 29.431 10.395 10.811
Pass / Fail
-60.00 26.558 27.136 15.268 15.733
Pass / Fail
-50.00 23.474 24.021 19.672 20.181
Pass / Fail
-40.00 19.672 20.181 23.474 24.021
Pass / Fail
-30.00 15.268 15.733 26.558 27.136
Pass / Fail
-20.00 10.395 10.811 28.830 29.431
Pass / Fail
-10.00 5.201 5.565 30.221 30.837
Pass / Fail
0.00 0.000 0.155 30.690 31.310
Pass / Fail
10.00 5.201 5.565 30.221 30.837
Pass / Fail
20.00 10.395 10.811 28.830 29.431
Pass / Fail
30.00 15.268 15.733 26.558 27.136
Pass / Fail
40.00 19.672 20.181 23.474 24.021
Pass / Fail
50.00 23.474 24.021 19.672 20.181
Pass / Fail
60.00 26.558 27.136 15.268 15.733
Pass / Fail
70.00 28.830 29.431 10.395 10.811
Pass / Fail
80.00 30.221 30.837 5.201 5.565
Pass / Fail
90.00 30.690 31.310 0.000 0.155
Pass / Fail
100.00 30.221 30.837 5.201 5.565
Pass / Fail
110.00 28.830 29.431 10.395 10.811
Pass / Fail
120.00 26.558 27.136 15.268 15.733
Pass / Fail
130.00 23.474 24.021 19.672 20.181
Pass / Fail
140.00 19.672 20.181 23.474 24.021
Pass / Fail
150.00 15.268 15.733 26.558 27.136
Pass / Fail
160.00 10.395 10.811 28.830 29.431
Pass / Fail
170.00 5.201 5.565 30.221 30.837
Pass / Fail
180.00 0.000 0.155 30.690 31.310
Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
