SECTION 7 - MAINTENANCE INFORMATION
Page 7.11
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
Table 7.10 - Linearity Verication Test Results For Resolver Simulator -xxxx04
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equip-
ment Used:
Position
Measured
Sin
Minimum Maximum
Measured
Cos
Minimum Maximum
Result (delete
as appropriate)
-180.00 0.000 0.078 15.345 15.655
Pass / Fail
-170.00 2.601 2.783 15.111 15.418
Pass / Fail
-160.00 5.197 5.405 14.415 14.716
Pass / Fail
-150.00 7.634 7.866 13.279 13.568
Pass / Fail
-140.00 9.836 10.091 11.737 12.011
Pass / Fail
-130.00 11.737 12.011 9.836 10.091
Pass / Fail
-120.00 13.279 13.568 7.634 7.866
Pass / Fail
-110.00 14.415 14.716 5.197 5.405
Pass / Fail
-100.00 15.111 15.418 2.601 2.783
Pass / Fail
-90.00 15.345 15.655 0.000 0.078
Pass / Fail
-80.00 15.111 15.418 2.601 2.783
Pass / Fail
-70.00 14.415 14.716 5.197 5.405
Pass / Fail
-60.00 13.279 13.568 7.634 7.866
Pass / Fail
-50.00 11.737 12.011 9.836 10.091
Pass / Fail
-40.00 9.836 10.091 11.737 12.011
Pass / Fail
-30.00 7.634 7.866 13.279 13.568
Pass / Fail
-20.00 5.197 5.405 14.415 14.716
Pass / Fail
-10.00 2.601 2.783 15.111 15.418
Pass / Fail
0.00 0.000 0.078 15.345 15.655
Pass / Fail
10.00 2.601 2.783 15.111 15.418
Pass / Fail
20.00 5.197 5.405 14.415 14.716
Pass / Fail
30.00 7.634 7.866 13.279 13.568
Pass / Fail
40.00 9.836 10.091 11.737 12.011
Pass / Fail
50.00 11.737 12.011 9.836 10.091
Pass / Fail
60.00 13.279 13.568 7.634 7.866
Pass / Fail
70.00 14.415 14.716 5.197 5.405
Pass / Fail
80.00 15.111 15.418 2.601 2.783
Pass / Fail
90.00 15.345 15.655 0.000 0.078
Pass / Fail
100.00 15.111 15.418 2.601 2.783
Pass / Fail
110.00 14.415 14.716 5.197 5.405
Pass / Fail
120.00 13.279 13.568 7.634 7.866
Pass / Fail
130.00 11.737 12.011 9.836 10.091
Pass / Fail
140.00 9.836 10.091 11.737 12.011
Pass / Fail
150.00 7.634 7.866 13.279 13.568
Pass / Fail
160.00 5.197 5.405 14.415 14.716
Pass / Fail
170.00 2.601 2.783 15.111 15.418
Pass / Fail
180.00 0.000 0.078 15.345 15.655
Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
