Page 7.10
SECTION 7 - MAINTENANCE INFORMATION
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
Table 7.9 - Linearity Verication Test Results For Resolver Simulator -xxxx03
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equip-
ment Used:
Position
Measured
Sin
Minimum Maximum
Measured
Cos
Minimum Maximum
Result (delete
as appropriate)
-180.00 0.000 0.039 7.623 7.777
Pass / Fail
-170.00 1.292 1.382 7.507 7.659
Pass / Fail
-160.00 2.582 2.685 7.161 7.310
Pass / Fail
-150.00 3.792 3.908 6.597 6.740
Pass / Fail
-140.00 4.886 5.013 5.831 5.967
Pass / Fail
-130.00 5.831 5.967 4.886 5.013
Pass / Fail
-120.00 6.597 6.740 3.792 3.908
Pass / Fail
-110.00 7.161 7.310 2.582 2.685
Pass / Fail
-100.00 7.507 7.659 1.292 1.382
Pass / Fail
-90.00 7.623 7.777 0.000 0.039
Pass / Fail
-80.00 7.507 7.659 1.292 1.382
Pass / Fail
-70.00 7.161 7.310 2.582 2.685
Pass / Fail
-60.00 6.597 6.740 3.792 3.908
Pass / Fail
-50.00 5.831 5.967 4.886 5.013
Pass / Fail
-40.00 4.886 5.013 5.831 5.967
Pass / Fail
-30.00 3.792 3.908 6.597 6.740
Pass / Fail
-20.00 2.582 2.685 7.161 7.310
Pass / Fail
-10.00 1.292 1.382 7.507 7.659
Pass / Fail
0.00 0.000 0.039 7.623 7.777
Pass / Fail
10.00 1.292 1.382 7.507 7.659
Pass / Fail
20.00 2.582 2.685 7.161 7.310
Pass / Fail
30.00 3.792 3.908 6.597 6.740
Pass / Fail
40.00 4.886 5.013 5.831 5.967
Pass / Fail
50.00 5.831 5.967 4.886 5.013
Pass / Fail
60.00 6.597 6.740 3.792 3.908
Pass / Fail
70.00 7.161 7.310 2.582 2.685
Pass / Fail
80.00 7.507 7.659 1.292 1.382
Pass / Fail
90.00 7.623 7.777 0.000 0.039
Pass / Fail
100.00 7.507 7.659 1.292 1.382
Pass / Fail
110.00 7.161 7.310 2.582 2.685
Pass / Fail
120.00 6.597 6.740 3.792 3.908
Pass / Fail
130.00 5.831 5.967 4.886 5.013
Pass / Fail
140.00 4.886 5.013 5.831 5.967
Pass / Fail
150.00 3.792 3.908 6.597 6.740
Pass / Fail
160.00 2.582 2.685 7.161 7.310
Pass / Fail
170.00 1.292 1.382 7.507 7.659
Pass / Fail
180.00 0.000 0.039 7.623 7.777
Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
