SECTION 7 - MAINTENANCE INFORMATION
Page 7.9
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
Table 7.8 - Linearity Verication Test Results For Resolver Simulator -xxxx02
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equip-
ment Used:
Position
Measured
Sin
Minimum Maximum
Measured
Cos
Minimum Maximum
Result (delete
as appropriate)
-180.00 0.000 0.019 3.762 3.838
Pass / Fail
-170.00 0.638 0.682 3.705 3.780
Pass / Fail
-160.00 1.274 1.325 3.534 3.608
Pass / Fail
-150.00 1.872 1.929 3.255 3.326
Pass / Fail
-140.00 2.411 2.474 2.877 2.945
Pass / Fail
-130.00 2.877 2.945 2.411 2.474
Pass / Fail
-120.00 3.255 3.326 1.872 1.929
Pass / Fail
-110.00 3.534 3.608 1.274 1.325
Pass / Fail
-100.00 3.705 3.780 0.638 0.682
Pass / Fail
-90.00 3.762 3.838 0.000 0.019
Pass / Fail
-80.00 3.705 3.780 0.638 0.682
Pass / Fail
-70.00 3.534 3.608 1.274 1.325
Pass / Fail
-60.00 3.255 3.326 1.872 1.929
Pass / Fail
-50.00 2.877 2.945 2.411 2.474
Pass / Fail
-40.00 2.411 2.474 2.877 2.945
Pass / Fail
-30.00 1.872 1.929 3.255 3.326
Pass / Fail
-20.00 1.274 1.325 3.534 3.608
Pass / Fail
-10.00 0.638 0.682 3.705 3.780
Pass / Fail
0.00 0.000 0.019 3.762 3.838
Pass / Fail
10.00 0.638 0.682 3.705 3.780
Pass / Fail
20.00 1.274 1.325 3.534 3.608
Pass / Fail
30.00 1.872 1.929 3.255 3.326
Pass / Fail
40.00 2.411 2.474 2.877 2.945
Pass / Fail
50.00 2.877 2.945 2.411 2.474
Pass / Fail
60.00 3.255 3.326 1.872 1.929
Pass / Fail
70.00 3.534 3.608 1.274 1.325
Pass / Fail
80.00 3.705 3.780 0.638 0.682
Pass / Fail
90.00 3.762 3.838 0.000 0.019
Pass / Fail
100.00 3.705 3.780 0.638 0.682
Pass / Fail
110.00 3.534 3.608 1.274 1.325
Pass / Fail
120.00 3.255 3.326 1.872 1.929
Pass / Fail
130.00 2.877 2.945 2.411 2.474
Pass / Fail
140.00 2.411 2.474 2.877 2.945
Pass / Fail
150.00 1.872 1.929 3.255 3.326
Pass / Fail
160.00 1.274 1.325 3.534 3.608
Pass / Fail
170.00 0.638 0.682 3.705 3.780
Pass / Fail
180.00 0.000 0.019 3.762 3.838
Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
