PicoScope 3000A Series Prog rammer's Guide 77
Copyright © 2011-2013 Pico Technology Limited. All rights reserved. ps3000abpg.en r9
2.12.48
ps3000aSetPulseWidthQualifier
PICO_STATUS ps3000aSetPulseWidthQualifier
(
short handle,
PS3000A_PWQ_CONDITIONS * conditions,
short nConditions,
PS3000A_THRESHOLD_DIRECTION direction,
unsigned long lower,
unsigned long upper,
PS3000A_PULSE_WIDTH_TYPE type
)
This function sets up pulse-width qualification, which can be used on its own for pulse-
width triggering or combined with level triggering or window triggering to produce more
complex triggers. The pulse-width qualifier is set by defining one or more structures
that are then ORed together. Each structure is itself the AND of the states of one or
more of the inputs. This AND-OR logic allows you to create any possible Boolean
function of the scope's inputs.
Applicability
All modes
Arguments
handle, the handle of the required device
* conditions, an array of PS3000A_PWQ_CONDITIONS
structures* specifying the conditions that should be applied to each
channel. In the simplest case, the array consists of a single element.
When there are several elements, the overall trigger condition is the
logical OR of all the elements. If conditions is NULL then the
pulse-width qualifier is not used.
nConditions, the number of elements in the conditions array.
If nConditions is zero then the pulse-width qualifier is not used.
Range: 0 to PS3000A_MAX_PULSE_WIDTH_QUALIFIER_COUNT.
direction, the direction of the signal required for the pulse width
trigger to fire. See PS3000A_THRESHOLD_DIRECTION constants
for the list of possible values. Each channel of the oscilloscope
(except the EXT input) has two thresholds for each direction—for
example, PS3000A_RISING and PS3000A_RISING_LOWER—so that
one can be used for the pulse-width qualifier and the other for the
level trigger. The driver will not let you use the same threshold for
both triggers; so, for example, you cannot use PS3000A_RISING as
the direction argument for both ps3000aSetTriggerConditions and
ps3000aSetPulseWidthQualifier at the same time. There is no such
restriction when using window triggers.
lower, the lower limit of the pulse-width counter, measured in
samples.
upper, the upper limit of the pulse-width counter, measured in
samples. This parameter is used only when the type is set to
PS3000A_PW_TYPE_IN_RANGE or
PS3000A_PW_TYPE_OUT_OF_RANGE.
