increment, the amount of frequency increase or decrease in sweep
mode
dwellTime, the time for which the sweep stays at each frequency,
in seconds
sweepType, whether the frequency will sweep from
startFrequency to stopFrequency, or in the opposite direction,
or repeatedly reverse direction. Use one of these constants:
PS3000A_UP
PS3000A_DOWN
PS3000A_UPDOWN
PS3000A_DOWNUP
operation, the type of waveform to be produced, specified by one
of the following enumerated types (MSO and B models only):
PS3000A_ES_OFF, normal signal generator operation specified by
wavetype.
PS3000A_WHITENOISE, the signal generator produces white noise
and ignores all settings except pkToPk and offsetVoltage.
PS3000A_PRBS, produces a random bitstream with a bit rate
specified by the start and stop frequency.
shots,
0: sweep the frequency as specified by sweeps
1...PS3000A_MAX_SWEEPS_SHOTS: the number of cycles of the
waveform to be produced after a trigger event. sweeps must be
zero.
PS3000A_SHOT_SWEEP_TRIGGER_CONTINUOUS_RUN: start and
run continuously after trigger occurs
sweeps,
0: produce number of cycles specified by shots
1..PS3000A_MAX_SWEEPS_SHOTS: the number of times to sweep
the frequency after a trigger event, according to sweepType.
shots must be zero.
PS3000A_SHOT_SWEEP_TRIGGER_CONTINUOUS_RUN: start a
sweep and continue after trigger occurs
triggerType, the type of trigger that will be applied to the signal
generator:
