BI-500 User Manual
Learning scan,communication, battery LEDs
Notifies the operating information of the scanner to the user by tone volume or sequence.
Division
LED [Left]
- Barcode reading
- Communication
LED [Right]
-Battery status Beep
Power On or Reset Purple/Red/Green/Blue Low/medium/high once
Power Off Red once time blink High once
USB connection Blue High once
USB disconnection - - Low/High Once
Barcode reading Green once time blink High once
Storage Overflow High 3 times
Data error Red 3 times blinks High once
Data delete Purple once time blink Low/medium/high once
All Data delete Purple once time blink Low/medium/high once
GPS disconnection Yellow 5sec blinks / cycle
BT connection Blue High once
BT disconnection Low/High Once
Battery not enough Blue
Battery charging Red
Full charged battery Green
