Pike MIRacle ATR - Table of Contents

PN 350-025004-09
Page | 1
Contents
Introduction
2
MIRacle ATR Accessory
3
MIRacle Pressure Clamp Options
3
MIRacle Universal Plate Options
4
Installation
4
Accessory Adjustment
5
Performance Verification
6
Sampling Procedures
8
Configuration for Liquid Sampling
8
Configuration for Solid Sampling
9
Pressure Clamp Tip Attachments
10
Micrometer Pressure Clamp
11
High-Pressure Clamps
12
High-Pressure Clamp Installation
12
Crystal Cleaning
12
ATR Spectrum
13
ATR Correction
14
Liquid Samples
15
Solid Samples
15
Useful Equations
16
Materials
16
Zinc Selenide
16
Germanium
17
Silicon
17
Diamond
17
Specifications
18
Effects of Temperature
18
Precautions
19
Mirrors
19
SAFETY
19
Replacement Parts and Options
20
