PNOZ 2
Operating Manual PNOZ 2
22151-EN-05
13
Technical details
Order no. 775800 – 775810
See below for more order numbers
General 775800 775810
Approvals
CCC, EAC (Eurasian), TÜV, cU-
Lus Listed
CCC, EAC (Eurasian), TÜV, cU-
Lus Listed
Electrical data 775800 775810
Supply voltage
Voltage 24 V 42 V
Kind AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 5 VA 5 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Duty cycle 100 % 100 %
Inputs 775800 775810
Number 1 1
Voltage at
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Start circuit DC 50 mA 50 mA
Feedback loop DC 50 mA 50 mA
Max. overall cable resistance Rl-
max
Single-channel at UB AC 45 Ohm 145 Ohm
Relay outputs 775800 775810
Number of output contacts
Safety contacts (N/O), instant-
aneous 3 3
Auxiliary contacts (N/C) 1 1
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 2000 VA 2000 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 200 W 200 W
