Pilz PNOZ 2 User Manual

PNOZ 2
Operating Manual PNOZ 2
22151-EN-05
15
Relay outputs 775800 775810
External contact fuse protection,
auxiliary contacts
Max. melting integral 240 A²s 240 A²s
Blow-out fuse, quick 10 A 10 A
Blow-out fuse, slow 6 A 6 A
Blow-out fuse, gG 10 A 10 A
Circuit breaker 24 V AC/DC,
characteristic B/C 6 A 6 A
Conventional thermal current 8 A 8 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Times 775800 775810
Switch-on delay
With automatic start typ. 150 ms 150 ms
With automatic start max. 250 ms 250 ms
With manual start typ. 150 ms 150 ms
With manual start max. 250 ms 250 ms
Delay-on de-energisation
With E-STOP typ. 50 ms 50 ms
With E-STOP, duty cycle ≥6s,
max. 100 ms 100 ms
With E-STOP, duty cycle <6s,
max. 250 ms 250 ms
With power failure typ. 50 ms 50 ms
With power failure max. 250 ms 250 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 250 ms 250 ms
After power failure 250 ms 250 ms
Environmental data 775800 775810
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
