Operating Manual PNOZ 2
22151-EN-05
17
Electrical data 775830 775850
Supply voltage
Voltage 110 V 230 V
Kind AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 5 VA 5 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Duty cycle 100 % 100 %
Inputs 775830 775850
Number 1 1
Voltage at
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Start circuit DC 50 mA 50 mA
Feedback loop DC 50 mA 50 mA
Max. overall line capacitance
Clmax 300 nF 75 nF
Relay outputs 775830 775850
Number of output contacts
Safety contacts (N/O), instant-
aneous 3 3
Auxiliary contacts (N/C) 1 1
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 2000 VA 2000 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 200 W 200 W
Utilisation category of auxiliary con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 2000 VA 2000 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 8 A 8 A
Max. power 200 W 200 W
