Pilz PNOZ 2 User Manual

PNOZ 2
Operating Manual PNOZ 2
22151-EN-05
19
Times 775830 775850
Delay-on de-energisation
With E-STOP typ. 50 ms 50 ms
With E-STOP, duty cycle ≥6s,
max. 100 ms 100 ms
With E-STOP, duty cycle <6s,
max. 250 ms 250 ms
With power failure typ. 50 ms 50 ms
With power failure max. 250 ms 250 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 250 ms 250 ms
After power failure 250 ms 250 ms
Environmental data 775830 775850
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III / II III / II
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 4 kV 4 kV
Protection type
Housing IP40 IP40
Terminals IP20 IP20
Mounting area (e.g. control cab-
inet) IP54 IP54
Mechanical data 775830 775850
Mounting position Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles
Material
Bottom PPO UL 94 V0 PPO UL 94 V0
Front ABS UL 94 V0 ABS UL 94 V0
Top PPO UL 94 V0 PPO UL 94 V0
