Operating Manual PNOZ X4
19894-EN-07
18
Relay outputs 774730 774731 774734
External contact fuse pro-
tection, auxiliary contacts
Max. melting integral 240 A²s 240 A²s 240 A²s
Blow-out fuse, quick 10 A 10 A 10 A
Blow-out fuse, slow 6 A 6 A 6 A
Blow-out fuse, gG 10 A 10 A 10 A
Circuit breaker 24 V
AC/DC, characteristic
B/C 6 A 6 A 6 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Conventional thermal
current while loading
several contacts
774730 774731 774734
Ith per contact at UB AC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact – 8 A 8 A
Conv. therm. current
with 2 contacts – 7,5 A 7,5 A
Conv. therm. current
with 3 contacts – 6,5 A 6,5 A
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 8 A – –
Conv. therm. current
with 2 contacts 8 A – –
Conv. therm. current
with 3 contacts 7 A – –
Times 774730 774731 774734
Switch-on delay
With automatic start
typ. 270 ms 210 ms 210 ms
With automatic start
max. 600 ms 350 ms 350 ms
With automatic start
after power on typ. 270 ms 240 ms 240 ms
With automatic start
after power on max. 600 ms 390 ms 390 ms
With manual start typ. 70 ms 55 ms 55 ms
With manual start max. 600 ms 350 ms 350 ms
With monitored start
typ. 40 ms 30 ms 30 ms
With monitored start
max. 70 ms 50 ms 50 ms

Pilz PNOZ X4 Specifications

General

Supply Voltage	24 V DC
Contacts	3 N/O, 1 N/C
Width	45 mm
Depth	121 mm
Mounting	DIN rail
PL according to EN ISO 13849-1	PL e
Category according to EN 954-1	4
SIL according to IEC 61508	SIL 3
Max. switching current	6 A
Protection class	IP20
Operating Temperature	-10 °C to +55 °C
Stop Category	0
SIL CL according to EN IEC 62061	SIL CL 3
Number of safe inputs	2
Number of safe outputs	3
Operating temperature range	-10 °C to +55 °C
