Pilz PSEN cs3.1a User Manual

PSEN cs3.1a/b
Operating Manual PSEN cs3.1a/b
1003295-EN-08
| 33
Semiconductor outputs 541061 541062
Short circuit-proof yes yes
Residual current at outputs 20 µA 20 µA
Voltage drop at OSSDs 3,5 V 3,5 V
Lowest operating current 0 mA 0 mA
Utilisation category in accordance
with EN 60947-1 DC-12 DC-12
Times 541061 541062
Test pulse duration, safety outputs 450 µs 450 µs
Switch-on delay
after UB is applied 1 s 1 s
Inputs typ. 13 ms 13 ms
Inputs max. 20 ms 20 ms
Actuator typ. 60 ms 60 ms
Actuator max. 150 ms 150 ms
Delay-on de-energisation
Inputs typ. 15 ms 15 ms
Inputs max. 20 ms 20 ms
Actuator typ. 40 ms 40 ms
Actuator max. 260 ms 260 ms
Risk time in accordance with EN
60947-5-3 260 ms 260 ms
Supply interruption before de-ener-
gisation 10 ms 10 ms
Simultaneity, channel 1 and 2 max. ∞ ∞
Environmental data 541061 541062
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range -25 - 70 °C -25 - 70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -25 - 70 °C -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78 EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
EMC EN 60947-5-3 EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm
Shock stress
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Acceleration 30g 30g
Duration 18 ms 18 ms
