Operating distances 541061 541062
Actuator 4
Typ PSEN cs3.1 low profile screw PSEN cs3.1 low profile screw
Assured operating distance Sao 5 mm 5 mm
Typical operating distance So 10 mm 10 mm
Assured release distance Sar 20 mm 20 mm
Typical release distance Sr 12 mm 12 mm
Repetition accuracy switching
distances 10 % 10 %
Change of operating distance
with temperature changes +-0,01mm/°C +-0,01mm/°C
Typical hysteresis 2 mm 2 mm
Mechanical data 541061 541062
Min. bending radius (fixed perman-
ently) K1 5 x Ø 5 x Ø
Min. bending radius (moving) K1 10 x Ø 10 x Ø
Cable diameter K1 5,55 mm 5,55 mm
Min. distance between safety
switches 100 mm 100 mm
Sensor flush installation in accord-
ance with EN 60947-5-2
Yes, follow installation
guidelines
Yes, follow installation
guidelines
Connection type 5 m cable 10 m cable
Cable Li9Y11Y 8 x 0,14 mm2 Li9Y11Y 8 x 0,14 mm2
Material
Top PBT PBT
Max. torque setting for fixing
screws 0,8 Nm 0,8 Nm
Dimensions
Height 37 mm 37 mm
Width 26 mm 26 mm
Depth 18 mm 18 mm
Weight of safety switch 205 g 380 g
Where standards are undated, the 2016-10 latest editions shall apply.
Technical details actuator
Order no. 540080 - 541080
See below for more order numbers
General 540080 541080
Certifications CE, EAC (Eurasian), TÜV, cULus
Listed
CE, EAC (Eurasian), TÜV, cULus
Listed
Sensor's mode of operation Transponder Transponder
Coding level in accordance with EN
ISO 14119 Low Low
Pilz coding type Coded Coded
