PSEN cs3.1a/b
Operating Manual PSEN cs3.1a/b
1003295-EN-08
| 36
Transponder 540080 541080
Frequency band 122 kHz - 128 kHz 122 kHz - 128 kHz
Environmental data 540080 541080
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range -25 - 70 °C -25 - 70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -40 - 85 °C -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78 EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
EMC EN 60947-5-3 EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm
Shock stress
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Acceleration 30g 30g
Duration 11 ms 18 ms
Protection type
Housing IP6K9K IP6K9K
Mechanical data 540080 541080
Material – PBT
Material
Top PBT –
Max. torque setting for fixing
screws 1 Nm 0,8 Nm
Dimensions
Height 11 mm 37 mm
Width 40 mm 18 mm
Depth 40 mm 18 mm
Weight 20 g 10 g
Order no. 541087 - 541088
General 541087 541088
Certifications CE, EAC (Eurasian), TÜV, cULus
Listed
CE, EAC (Eurasian), TÜV, cULus
Listed
Sensor's mode of operation Transponder Transponder
Coding level in accordance with EN
ISO 14119 Low Low
Pilz coding type Coded Coded
Transponder 541087 541088
Frequency band 122 kHz - 128 kHz 122 kHz - 128 kHz
