Technical details safety switch
General 541061 541062
Certifications CE, EAC (Eurasian), FCC, IC,
TÜV, cULus Listed
CE, EAC (Eurasian), FCC, IC,
TÜV, cULus Listed
Sensor's mode of operation Transponder Transponder
Coding level in accordance with EN
ISO 14119 Low Low
Design in accordance with EN ISO
14119 4 4
Classification in accordance with
EN 60947-5-3 PDDB PDDB
Pilz coding type Coded Coded
Transponder 541061 541062
Frequency band 122 kHz - 128 kHz 122 kHz - 128 kHz
Max. transmitter output 15 mW 15 mW
Electrical data 541061 541062
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -20 %/+20 % -20 %/+20 %
Output of external power supply
(DC) 1 W 1 W
Max. switching frequency 3 Hz 3 Hz
Max. cable capacitance at the
safety outputs
No-load, PNOZ with relay con-
tacts 400 nF 400 nF
PNOZmulti, PNOZelog, PSS 400 nF 400 nF
Max. inrush current impulse
Current pulse, A1 0,58 A 0,58 A
Pulse duration, A1 1 ms 1 ms
No-load current 20 mA 20 mA
Inputs 541061 541062
Number 2 2
Voltage at inputs 24 V DC 24 V DC
Input current range 5 mA 5 mA
Max. overall cable resistance Rl-
max
Single-channel at UB DC 1000 Ohm 1000 Ohm
Semiconductor outputs 541061 541062
OSSD safety outputs 2 2
Signal outputs 1 1
Switching current per output 100 mA 100 mA
Breaking capacity per output 2,4 W 2,4 W
Potential isolation from system
voltage No No
