PSEN cs3.1a/b
Operating Manual PSEN cs3.1a/b
1003295-EN-08
| 37
Environmental data 541087 541088
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range -25 - 70 °C -25 - 70 °C
Max. at max. operating height +60 °C +60 °C
Max. at max. operating height
<2000 m +70 °C +70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
In accordance with the standard EN 60068-2-30 EN 60068-2-30
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Max. operating height above sea
level 4000 m 4000 m
EMC EN 60947-5-3 EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm
Shock stress
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Acceleration 30g 30g
Duration 11 ms 11 ms
Protection type
Housing IP67 IP67
Mechanical data 541087 541088
Material
Top PBT PBT
Max. torque setting for fixing
screws – 0,1 Nm
Dimensions
Height 3,8 mm 3,8 mm
Width 18 mm 18 mm
Depth 18 mm 18 mm
Weight 2 g 2 g
Where standards are undated, the 2016-10 latest editions shall apply.
