Pilz PSEN sc M 3.0 08-17 User Manual

Technical details order no. 6D000020-6D000021
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 131
Optical data 6D000020 6D000021
Typical output power laser 8 mW 8 mW
Inputs 6D000020 6D000021
Signal level at "0" < 5 V < 5 V
Signal level at "1" > 12 V > 12 V
Voltage at inputs 24 V 24 V
Current per input 2 mA 2 mA
Input resistance 12 kOhm 12 kOhm
Semiconductor outputs 6D000020 6D000021
Residual current at "0" signal < 700 µA < 700 µA
Output voltage at "1" signal 17,2 V 17,2 V
Output voltage at "0" signal 0 V 0 V
Max. output current at rated
voltage 250 mA 250 mA
Max. capacitive load 2,2 µF 2,2 µF
Ethernet interface 6D000020 6D000021
Number 1 1
Connection type M12x1, 4-pin, D-code M12x1, 4-pin, D-code
Transmission rate 100 MBit/s 100 MBit/s
Times 6D000020 6D000021
Test pulse duration, safety outputs 300 µs 300 µs
Switch-on delay
after UB is applied 120 s 120 s
Increased response time per meas-
urement cycle 30 ms 30 ms
Response time t1 62 ms 62 ms
Rotation time 30 ms 30 ms
Environmental data 6D000020 6D000021
Ambient temperature
Temperature range -10 - 50 °C -10 - 50 °C
Storage temperature
Temperature range -20 - 70 °C -20 - 70 °C
Climatic suitability
Humidity max. 95 % max. 95 %
Condensation during operation Not permitted Not permitted
Max. operating height above sea
level 2000 m 2000 m
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
