Appendix
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 140
Action OK Not OK Notes
Check minimum distance to danger
zone
Has the minimum distance been calcu-
lated in accordance with the applicable
standards?
Has the calculated minimum distance
been maintained at all points?
Check safety zone
Has the ability to creep underneath the
safety zone undetected been ex-
cluded?
Check safety laser scanner
Make sure that there are no objects in
front of the safety laser scanner (e.g.
trailing cables, crossbeams, struts,
covers, etc.).
Make sure that there are no transpar-
ent materials between the monitored
safety zone and the safety laser scan-
ner (such as the glass panel).
Is the safety laser scanner fixed cor-
rectly?
Are all the electrical connections to the
safety laser scanner wired correctly?
Check loaded configuration after
switching on
Was the correct configuration loaded
after switching on the safety laser
scanner?
Check the effectiveness of the
safety laser scanner during the haz-
ardous movement
Is the safety laser scanner effective
throughout the whole of the hazardous
movement of the plant/machine?
