GM-8027ZT/WL
Unit Number : CWM8076(GM-8027ZT/WL)
: CWM8074(GM-8027ZT/E)
: CWM8356(GM-8127ZT/WL)
: CWM8353(GM-8127ZT/EW)
Unit Name : DSP Unit
MISCELLANEOUS
IC 101 IC(GM-8027ZT/WL,GM-8027ZT/E) PD5726A
IC 101 IC(GM-8127ZT/WL,GM-8127ZT/EW) PD5792A
IC 131 IC S-80730ANDT
IC 141 IC HA12187FP
IC 181 IC AK5351VF
IC 201 IC PD2061A
IC 231 IC TC7WU04F
IC 241 IC TC7W74FU
IC 251 IC PD2061A
IC 261 IC AK4321VF
IC 271 IC AK4321VF
IC 281 IC AK4321VF
IC 291 IC AK4321VF
IC 311 IC NJM2068MD
IC 321 IC NJM2068MD
IC 331 IC NJM2068MD
IC 341 IC NJM2068MD
IC 351 IC PM0017AM
IC 371 IC SN761029DL
IC 401 IC NJM2068MD
IC 402 IC NJM2068MD
Q 101 Transistor DTA144EK
Q 151 Chip Transistor 2SC2712
Q 155 Chip Transistor 2SC2712
Q 161 Chip Transistor 2SC2712
Q 171 Transistor 2SA1162
Q 175 Transistor 2SA1162
Q 291 Transistor DTA124XK
Q 401 Chip Transistor 2SC2712
D 101 Diode DAN202K
D 151 Diode HZU8R2(B1)
D 155 Diode HZU8R2(B1)
D 301 Diode HZU4R3(B3)
D 401 Diode HZU4R3(B3)
D 402 Diode 1SS355
D 403 Diode 1SS355
D 404 Diode 1SS355
D 405 Diode 1SS355
D 406 Diode 1SS355
D 451 Diode RD2R7M(B2)
L 101 Inductor LCTB1R0K2125
L 141 Inductor CTF1305
L 142 Inductor CTF1305
L 181 Inductor LCTB1R0K2125
L 182 Inductor LCTB1R0K2125
L 183 Inductor LCTB1R0K2125
L 184 Inductor LCTB1R0K2125
L 185 Inductor LCTB4R7K2125
L 186 Inductor LCTB120K2125
L 201 Inductor LCTBR82K2125
L 231 Inductor LCTB1R0K2125
L 241 Inductor LCTB1R0K2125
L 251 Inductor LCTBR82K2125
L 261 Inductor LCTB1R0K2125
L 262 Inductor LCTB120K2125
L 271 Inductor LCTB1R0K2125
L 272 Inductor LCTB120K2125
L 281 Inductor LCTB1R0K2125
L 282 Inductor LCTB120K2125
L 291 Inductor LCTB1R0K2125
L 292 Inductor LCTB120K2125
L 293 Inductor LCTB1R0K2125
L 295 Inductor LCTA1R0J3225
L 296 Chip-Inductor LCTA2R2J3225
L 297 Chip-Inductor LCTA2R2J3225
L 301 Inductor LCTB1R0K2125
L 451 Inductor LCTB4R7K2125
X 101 Radiator 10.00MHz CSS1428
X 231 Ceramic Resonator 22.5792MHz CSS1512
VR 401 Semi-fixed 1kΩ(OB) CCP1393
RESISTORS
R 101 1kΩ CCN1120
R 103 RS1/10S473J
R 104 (GM-8027ZT/E,GM-8127ZT/EW) RS1/10S473J
R 105 RS1/10S103J
R 107 RS1/10S473J
R 108 RS1/10S102J
R 109 RS1/10S473J
R 110 (GM-8027ZT/WL,GM-8127ZT/WL) RS1/10S473J
R 111 RS1/10S102J
R 112 RS1/10S473J
R 113 RS1/10S473J
R 114 RS1/10S473J
R 115 RS1/10S472J
R 116 RS1/10S472J
R 117 RS1/10S103J
R 118 RS1/10S681J
R 119 47kΩ CCN1131
R 120 RS1/10S473J
R 122 RS1/4S271J
R 125 RS1/16S102J
R 126 RS1/16S102J
R 127 RS1/16S102J
R 128 RS1/16S102J
R 129 RS1/16S102J
R 130 RS1/16S102J
5. ELECTRICAL PARTS LIST
NOTE:
- Parts whose parts numbers are omitted are subject to being not supplied.
- The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
